GCR15 P4 Precision Spindle Cylinder Roller Bearing NN3028MBKRCC9P4

Brand Name : NSK/OEM

Model Number : NN3028MBKRCC9P5

Certification : ISO9001:2008

Place of Origin : Japan

MOQ : 1 pcs

Price : negotiation

Payment Terms : T/T or western Union or PayPal

Supply Ability : 3,000pcs per month

Delivery Time : 3 working days after received your payment

Packaging Details : Packed in carton firstly,and then reinforced with wooden case for outer packing

Structure : Cylindrical

Type : Roller

Material : Chrome steel

Application : Vibration machinary,CNC machine and so on

weight : 6 kg

Cage : Brass cage

Contact Now

NN3028MBKRCC9P4 Cylindrical Roller Bearing



Bearing name :bearing for CNC machine cylindrical roller bearing

Model : NN3028MBKRCC9P4

Size : 140*210*53 mm

Weight : 6 KG

Material : GCR-15

Precision : P4

Quality : ISO9001:2008 approved

OEM service: Offer



Types of cylindrical roller bearing:

. Single row cylindrical roller bearing: NU, NJ, NUP, NUB series

. Double row cylindrical roller bearings:NNU series

. Four row cylindrical roller bearing:FC series

. Single row full complement cylindrical roller bearing:SL18 series, SL 19 series

. Double row full complement cylindrical roller bearing

. SL01 series, SL02 series, SL18 series.





Bearing type Cage symbol Specification Available size
NN MB Roller guided machined brass cage

NN3005,NN3026-NN3040

NN3920-NN3956,NN4920-NN4940
TB Roller guided PPS resin cage NN3006-NN3024
NNU MB Roller guided machined brass cage NNU4920-NNU4940
N MR Roller guided machined brass cage N1006-N1028
TP Outer ring guided PEEK resin cage N1009-N1017



Import NSK precision spindle Cylindrical roller bearing NN3026MBKRCC1P5 design draft :

GCR15 P4 Precision Spindle Cylinder Roller Bearing NN3028MBKRCC9P4



Cylindrical roller bearings NN3028MBKRCC9P4

Bearing number : NN3028MBKR

Size (mm) : 140x210x53

Brand : NSK

Bore Diameter (mm) : 140

Outer Diameter (mm) : 210

Width (mm) : 53

Bearing dimensions and specification in brand catalogue :

d - 140 mm

D - 210 mm

E - 192 mm

B - 53 mm

C - 53 mm

r min. - 4800

Weight - 6 Kg

Basic dynamic load rating (C) - 297 kN

Basic static load rating (C0) - 520kN

(Grease) Lubrication Speed -4000 r/min



(Oil) Lubrication Speed - 4500 r/min

GCR15 P4 Precision Spindle Cylinder Roller Bearing NN3028MBKRCC9P4GCR15 P4 Precision Spindle Cylinder Roller Bearing NN3028MBKRCC9P4



Dimension

(mm)

 Weight (kg)

Rated load

( KN)

Limiting speed

(r/min)

 Type
d D B r min F E Cr Cor Grease oil
100 140 40 1.1 113 137 1.88 125 244 4300 5100 NNU4920
150 37 1.5 -- 146 245 4000 4800 NN3020
105 145 40 1.1 118 146 1.96 132 270 4100 4800 NNU4921
160 41 2 -- 2.96 192 310 3800 4100 NN3021
110 150 40 1.1 123 155 2.04 132 258 3900 4600 NNU4922
170 45 2 -- 3.76 226 365 3600 4300 NN3022
120 165 45 1.1 134.5 165 2.76 170 328 3600 4200 NNU4924
200 80 1.112 141 11 -- -- -- -- NNU4124
180 46 2 -- 4.1 232 390 3300 3900 NN3024
130 180 50 1.5 146 182 3.79 187 368 3300 3900 NNU4926
200 52 2 -- 6.04 284 475 3100 3600

NN3026





If you want to buy NSK NN3028MBKRCC9P4 bearing,just contact us.










Product Tags:

GCR15 Cylinder Roller Bearing



P4 Precision Spindle Cylinder Roller Bearing



Chrome Steel Cylinder Roller Bearing


Buy cheap GCR15 P4 Precision Spindle Cylinder Roller Bearing NN3028MBKRCC9P4 product

GCR15 P4 Precision Spindle Cylinder Roller Bearing NN3028MBKRCC9P4 Images
