High Precision XSU140744 Slew Ring Bearing 674x814x56mm Cross Roller CNC Turntable Bearing

Brand Name : GQZ

Model Number : XSU140744

Certification : ISO9001/ISO14001/GJB9001

Place of Origin : China

MOQ : 5pcs

Price : $719-$730

Payment Terms : T/T or western Union or PayPal

Supply Ability : 3,000pcs per month

Delivery Time : 3 working days after received your payment

Packaging Details : Packed in carton firstly,and then reinforced with wooden case for outer packing

Material : GCr15 Bearing Steel

Product Name : Crossed Roller Bearing

ID(mm) : 674

OD(mm) : 814

Width(mm) : 56

Precision Rating : P4

Structure : Tapered Roller Bearing

Warranty : 12 Months

Contact Now

High Precision XSU140744 Slew Ring Bearing 674x814x56mm | Cross Roller CNC Turntable Bearing
Product Overview

The XSU140744 Slew Ring Bearing is a high-precision cross roller bearing designed for CNC machine parts, rotary tables, and industrial automation systems. With dimensions of 674mm inner diameter, 814mm outer diameter, and 56mm width, it delivers compact structure, superior rigidity, and excellent rotational accuracy.

Featuring a crossed roller structure, this bearing ensures smooth motion, high stability, and uniform load distribution, making it ideal for precision positioning and high-performance CNC applications.

  • Model: XSU140744
  • Size: 674x814x56mm
  • Type: Slewing Ring / Cross Roller Bearing
  • Structure: Crossed cylindrical rollers
  • Designed for CNC and automation systems

Key Features
  • High Precision Design: Ideal for demanding CNC machining applications.
  • Cross Roller Structure: Ensures smooth rotation and high rigidity.
  • Compact Slew Ring: Space-saving design with strong load capacity.
  • Multi-Directional Load Support: Handles radial, axial, and moment loads.
  • Turntable Optimization: Perfect for rotary tables and positioning systems.
  • Durable Construction: High-quality bearing steel for long service life.

Technical Specifications
Parameter Specification
Model XSU140744
Inner Diameter (ID) 674 mm
Outer Diameter (OD) 814 mm
Width (H) 56 mm
Type Slewing Ring Bearing
Structure Crossed Cylindrical Rollers
Material Bearing Steel
Accuracy Class P5 / P4 optional
Preload Custom
Application CNC Machine Parts, Turntables, Automation Equipment

Applications
  • CNC Machine Parts – High precision machining and positioning.
  • Rotary Tables – Smooth and accurate rotational movement.
  • Industrial Automation – Stable motion control systems.
  • Robotics – Precision rotation in robotic applications.
Product Series Specifications
INA Weight (Kg) Da di La ni/na Li Di da A B C D Preload
XSU140414N 28 484 344 460 24 468 415 413 0.04 0.04 0.06 0.06 0.01-0.03
XSU140544N 38 614 474 590 32 598 545 543 0.04 0.04 0.07 0.06 0.01-0.03
XSU140644N 44 714 574 690 36 698 645 643 0.05 0.05 0.08 0.07 0.01-0.04
XSU140744N 52 814 674 790 40 798 745 743 0.05 0.05 0.09 0.08 0.01-0.04
XSU140844N 60 914 774 890 40 898 845 843 0.06 0.06 0.09 0.09 0.01-0.04
XSU140944N 67 1014 874 990 44 998 945 943 0.06 0.06 0.11 0.09 0.01-0.05
XSU141094N 77 1164 1024 1140 48 1148 1095 1093 0.07 0.07 0.11 0.11 0.01-0.05
Why Choose GQZ Bearing?
  • Slewing Ring & Cross Roller Expertise
  • High Precision Manufacturing
  • Stable Performance for CNC Systems
  • Customization & Global Delivery Support
Product Images

High Precision XSU140744 Slew Ring Bearing 674x814x56mm Cross Roller CNC Turntable Bearing

High Precision XSU140744 Slew Ring Bearing 674x814x56mm Cross Roller CNC Turntable Bearing

High Precision XSU140744 Slew Ring Bearing 674x814x56mm Cross Roller CNC Turntable Bearing

High Precision XSU140744 Slew Ring Bearing 674x814x56mm Cross Roller CNC Turntable Bearing

High Precision XSU140744 Slew Ring Bearing 674x814x56mm Cross Roller CNC Turntable Bearing

Frequently Asked Questions

Q1: What makes XSU140744 suitable for CNC applications?A1: Its high precision and cross roller structure ensure accurate and stable rotation.

Q2: Is it suitable for rotary tables?A2: Yes, it is widely used in turntable and positioning systems.

Q3: Do you support customization?A3: Yes, customization is available for preload, precision grade, and materials.

Enhance your CNC performance with XSU140744 High Precision Slew Ring Bearing.Contact GQZ Bearing today for pricing, samples, or technical consultation!
