XSU140414 Slewing Ring Bearing 344x484x56mm Cross Roller Bearing for CNC Machinery Parts

Brand Name : GQZ

Model Number : XSU140414

Certification : ISO9001/ISO14001/GJB9001

Place of Origin : China

MOQ : 5pcs

Price : $190-$209

Payment Terms : T/T or western Union or PayPal

Supply Ability : 3,000pcs per month

Delivery Time : 3 working days after received your payment

Packaging Details : Packed in carton firstly,and then reinforced with wooden case for outer packing

Material : GCr15 Bearing Steel

Product Name : Crossed Roller Bearing

ID(mm) : 344

OD(mm) : 484

Width(mm) : 56

Precision Rating : P4

Structure : Tapered Roller Bearing

Warranty : 12 Months

Contact Now

XSU140414 Slewing Ring Bearing 344x484x56mm Cross Roller Bearing for CNC Machinery Parts
Product Overview

The XSU140414 Slewing Ring Bearing is a high-precision cross roller cylindrical bearing designed for CNC machinery parts, rotary tables, and industrial automation systems. With dimensions of 344mm inner diameter, 484mm outer diameter, and 56mm width, it offers compact structure, high rigidity, and excellent rotational accuracy.

Featuring a crossed cylindrical roller design, this bearing ensures smooth motion and stable load distribution, making it ideal for applications requiring precision and reliability.

  • Model: XSU140414
  • Size: 344x484x56mm
  • Type: Slewing Ring / Cross Roller Bearing
  • Structure: Crossed cylindrical rollers
  • Designed for CNC and precision machinery
Key Features
  • Integrated Slewing Ring Design: Compact structure with high load capacity.
  • Crossed Cylindrical Rollers: Ensures high precision and smooth rotation.
  • High Rigidity: Suitable for demanding CNC and automation applications.
  • Multi-Directional Load Capacity: Handles radial, axial, and moment loads.
  • Precision Rotation: Ideal for rotary tables and positioning systems.
  • Durable Construction: High-quality bearing steel for long service life.
Technical Specifications
Parameter Specification
Model XSU140414
Inner Diameter (ID) 344 mm
Outer Diameter (OD) 484 mm
Width (H) 56 mm
Type Slewing Ring Bearing
Structure Crossed Cylindrical Rollers
Material Bearing Steel
Accuracy Class P5 / P4 optional
Preload Custom
Application CNC Machinery Parts, Rotary Tables, Automation Equipment
Applications
  • CNC Machinery Parts – High precision machining and positioning.
  • Rotary Tables – Smooth and accurate rotation.
  • Industrial Automation – Stable motion control systems.
  • Robotics – Precise movement in robotic joints and platforms.

INA Weight (Kg) Da di La ni/na Li Di da A B C D Preload
XSU140414N 28 484 344 460 24 468 415 413 0.04 0.04 0.06 0.06 0.01-0.03
XSU140544N 38 614 474 590 32 598 545 543 0.04 0.04 0.07 0.06 0.01-0.03
XSU140644N 44 714 574 690 36 698 645 643 0.05 0.05 0.08 0.07 0.01-0.04
XSU140744N 52 814 674 790 40 798 745 743 0.05 0.05 0.09 0.08 0.01-0.04
XSU140844N 60 914 774 890 40 898 845 843 0.06 0.06 0.09 0.09 0.01-0.04
XSU140944N 67 1014 874 990 44 998 945 943 0.06 0.06 0.11 0.09 0.01-0.05
XSU141094N 77 1164 1024 1140 48 1148 1095 1093 0.07 0.07 0.11 0.11 0.01-0.05
Why Choose GQZ Bearing?
  • Slewing Ring & Cross Roller Expertise
  • High Precision Manufacturing
  • Stable Performance for CNC Systems
  • Customization & Global Delivery Support
XSU140414 Slewing Ring Bearing 344x484x56mm Cross Roller Bearing for CNC Machinery Parts
XSU140414 Slewing Ring Bearing 344x484x56mm Cross Roller Bearing for CNC Machinery Parts
XSU140414 Slewing Ring Bearing 344x484x56mm Cross Roller Bearing for CNC Machinery Parts
XSU140414 Slewing Ring Bearing 344x484x56mm Cross Roller Bearing for CNC Machinery Parts
FAQ

Q1: What type of bearing is XSU140414?
A1: It is a slewing ring bearing with crossed cylindrical roller structure.

Q2: Is it suitable for CNC machinery?
A2: Yes, it is designed for high-precision CNC and automation systems.

Q3: Do you offer customization?
A3: Yes, we support customization for preload, accuracy class, and materials.

Upgrade your CNC system with XSU140414 Slewing Ring Cross Roller Bearing.
Contact GQZ Bearing today for pricing, samples, or technical consultation!
